Sound Level Monitoring

Sound Level Monitoring

2020-03-30T08:36:58+02:00

Sound Level Monitoring When assessing sound levels, for instance in public urban areas, it’s important that the measured sound levels are reliable, accurate and traceable. Therefore, it is required to use a type-approved, accredited and calibrated Sound Level Meter, which measures correctly under changing environmental conditions like temperature, humidity, and wind speed. Such installations [...]

Learn More
© Copyright 2017- | The MONICA Project | All Rights Reserved |

SMC-2 Adaptive Sound Field Control
Audio wiring scheme for AFSC system


The wiring scheme for the ASFC system is shown in the figure below. The ASFC system is connected to the primary loudspeakers via the sniffers and to the wireless microphones via the MONICA cloud. All internal components are connected via a DANTE network.

AFSC Audio Wiring Scheme

AFSC Audio Wiring Scheme at the Tivoli Fredagssrock 2018

The DANTE protocol was selected for connecting ASFC system components because the distances between the components can be very long compared to standard audio device setup. To ensure the reliable signal transmission over several hundreds of meters, signal routing over ethernet cable is the most suitable approach. The ASFC system requires monitoring a high number of PA channels, but this can easily be done with the DANTE protocol.

SMC-2 Adaptive Sound Field Control
Results from the Adaptive Sound Field Control system


During the cause of the MONICA project, the ASFC system has evolved from a lab-setup demonstrating the potential for low-frequency reductions in large dark zones, to a fully demonstrated field setup showing remarkable progress in performance from demo to demo. The sound field control has been successfully applied in outdoor conditions in a controlled scenario in Refshaleøen in Copenhagen presenting results up to 14 dB of sound reduction and in a real concert event Kappa FuturFestival in Torino with 6 to 8 dB. Test during Fredagsrock 2018 in Tivoli had to be cancelled due to bad weather, but a final demo in Roskilde College Concert in 2019 with new, improved propagation models showed very promising results. The basis for the consecutive improvements in performance is substantial refinements introduced in every link in the ASFC chain.

First demo: Kappa FuturFestival, Torino 2018

The experimental setup can be seen in the picture below.

Control subwoofers at Kappa FuturFestival 2018

Control subwoofers at Kappa FuturFestival 2018 - the festival stage can be seen in the back

Insertion loss at the Kappa FuturFestival 2018

Insertion loss measured with previous days filters at the Kappa FuturFestival 2018

The dark zone was placed in a nearby church yard and the secondary sources at the boarder of the festival area. Transfer functions were measured from the stage system and the secondary sources the day before the festival. For the measurement, 120 microphone positions were used.

The resulting insertion loss was measured during day one of the festival with filters computed from the day before. The results showed good results with a level of reduction of between 2-8dB. No sound propagation model was used in this pilot demonstration and a number of structures around the bright zone created some reflections that were not compensated.

Second demo: Tivoli Fredagsrock, Copenhagen 2018

The experimental setup can be seen in the diagram below. The dark zone was in the residential area behind the large Tivoli Concert Hall building. The secondary source array loudspeakers were placed on the roof of the Tivoli Concert Hall. Transfer functions were measured from the stage system and the secondary sources the day before the festival.

Secondary sources at the Tivoli Fredagsrock 2018

Secondary sources (in red) at the Tivoli Fredagsrock 2018 on top of the Tivoli Concert Hall and the dark zone located on the other side of the street (in blue)

The results showed good results with a level of reduction of around 10dB. A basic sound propagation model was used. The day of the training before the festival was a sunny day and with low wind. Unfortunately, the day of the demonstration was rainy and windy and the propagation model did not work as expected. However, the lessons learned from this made much needed input for the adaptive propagation models under development.

Third demo: Sound2019, Roskilde College 2019

The final demonstration was carried out at a concert at the Roskilde College, Denmark in 2019. For this demonstration, a fully developed with adaptive propagation models using the coherence method. In the coherence method, synchronized signal data is obtained from sensors close to the source (‘reference’ signal), and at locations where people are potentially annoyed (‘remote’ signal). The goal was to find the coherent part of the reference signal in the recordings, and from that to estimate the contribution of the concert. The coherence method requires audio recordings to be transferred to the cloud to perform the required contribution analysis. This necessitates a stable network that can transfer a relatively high rate of data (1 Mbit/sec) which was at hand at the Roskilde demo. The setup for the Contribution Analysis is presented in the figure below.

Contribution Analysis at Sound2019, Roskilde

Contribution Analysis at Sound2019 - the Reference SLM is located near the Audience, the remote SLM is placed in the Dark zone

SMC-2 Adaptive Sound Field Control
Adaptive Sound Field Controller


The basic function of the Adaptive Sound Field Controller is to optimize the radiation from the secondary sources in such a way, that the sum of sound pressures from the primary and secondary sources effectively reduces the total sound pressure level in the dark zone. The use of additional loudspeakers to control the sound in the dark zone must not negatively impact the sound experience in the audience area, the bright zone. This restriction must be included in the loudspeaker configuration design by either using directive loudspeakers facing away from the bright zone for the secondary sources or in the formulation of the loudspeaker signal optimization problem.

The figure below shows a schematic of the information flow in the acoustic closed-loop system. Compared to a traditional sound reinforcement chain, a Sound Field Controller is inserted, which is a processing unit in between the mixer and the loudspeaker system and computes the optimal loudspeaker signals. IoT enabled microphones and weather sensors are distributed throughout the venue and the control areas continuously measure the sound pressure field created by the ASFC system and current weather conditions. This data is made available to the Sound Propagation Module via the MONICA IoT platform. The Sound Propagation Module uses this data to estimate the transfer-functions between sound sources and the control areas, which are needed by the Sound Field Controller's optimization routine.

Information flow in ASFC

Information flow in the Adaptive Sound Field Control system
